Three Phase Oil Cooled Isolation Transformer

A Three Phase Oil Cooled Isolation Transformer is a heavy-duty electrical device designed to provide electrical isolation between the primary and secondary circuits in three-phase power systems. The oil cooling mechanism ensures efficient heat dissipation, making it ideal for environments with high power demands and continuous operation. Here’s an in-depth look at this type of transformer:

Key Features and Components:

Primary and Secondary Windings:
- Function: The primary winding receives the input voltage, while the secondary winding delivers the output voltage.
- Benefit: Electrical isolation between the windings ensures no direct electrical connection exists between the input and output, providing safety and protection.
Core Material:
- Function: Usually made of laminated silicon steel, the core helps to efficiently transfer the magnetic flux between the windings.
- Benefit: Enhances the transformer’s efficiency by reducing energy losses.
Insulation:
- Function: High-quality insulation materials are used between windings to ensure electrical isolation.
- Benefit: Prevents electrical leakage and enhances safety.
Shielding:
- Function: Electrostatic shielding is sometimes used between windings to reduce noise and interference.
- Benefit: Improves the quality of the output by minimizing electrical noise.
Oil Cooling System:
- Function: Uses oil as a cooling medium to dissipate heat generated by the transformer.
- Benefit: Provides efficient cooling, making it suitable for high-capacity and continuous operations.
Enclosure:

- Function: Provides physical protection to the transformer components.
- Benefit: Protects the transformer from environmental factors and mechanical damage.

Benefits:

Electrical Isolation: Enhances safety by isolating the primary and secondary circuits, preventing the passage of harmful transients and DC currents.
Noise Reduction: Reduces electrical noise and interference, improving the quality of the power supply to sensitive equipment.
Protection: Protects sensitive electronic equipment from electrical faults, surges, and transients on the supply side.
Safety: Prevents electrical shock hazards by ensuring no direct electrical connection between input and output circuits.
Voltage Transformation: Can step up or step down voltage levels as required for specific applications.
Enhanced Cooling: Oil cooling provides better heat dissipation, essential for high-power applications and continuous operation.

Applications:

Industrial Machinery:
- Example: Large CNC machines, heavy-duty manufacturing equipment.
- Benefit: Ensures consistent voltage for optimal performance and reduces the risk of machinery damage.
Commercial Buildings:
- Example: Office buildings, shopping malls, data centers.
- Benefit: Stabilizes voltage for HVAC systems, lighting, and office equipment, ensuring smooth operations.
Medical Facilities:
- Example: Hospitals, diagnostic centers.
- Benefit: Provides stable power supply to prevent malfunction or damage to critical medical devices.
Telecommunication Systems:
- Example: Large data centers, communication hubs.
- Benefit: Ensures a stable and noise-free power supply, enhancing communication reliability.
Educational Institutions:

- Example: Universities, research facilities.
- Benefit: Protects sensitive electronic equipment used in academic settings.

Installation and Maintenance:

Installation:
- Should be carried out by qualified technicians to ensure proper setup and safety.
- Requires adequate space for proper ventilation and cooling.
- Should be placed on a stable, vibration-free surface.
Maintenance:

- Regular inspection of oil levels and quality to ensure efficient cooling.
- Periodic cleaning and replacement of oil filters.
- Checking electrical connections and components for wear and tear.
- Periodic testing of the transformer’s performance to ensure it is operating within specified parameters.

A Three Phase Oil Cooled Isolation Transformer, such as the TIOC-100KVA model, is essential for providing electrical isolation, noise reduction, and protection in various applications. Its advanced design and efficient oil cooling system ensure safety and reliability, making it suitable for industrial machinery, commercial buildings, medical facilities, telecommunication systems, and educational institutions. Proper installation and regular maintenance are crucial to ensuring the optimal performance and longevity of the transformer.
